| Wireless specifications | 2.4GHz 2*2: maximum rate 400Mbps; 5GHz 2*2: maximum rate 867Mbps |
| Antenna: External 6dBi non-removable omnidirectional antennas |
| Support 802.11a/b/g/n/ac/ac Wave2, MU-MIMO |
| Frequency band: Independent 2.4GHz and 5GHz modules, supporting dual frequency integration |
| Support beamforming |
| Wi-Fi channel: |
| 2.4GHz Channel： 1,2,3,4,5,6,7,8,9,10,11,12,13 |
| 5GHz Channel： 36,40,44,48,149,153,157,161,165 |
| Ports | 1 10/100/1000M WAN port（Auto MDI/MDIX） |
| 3 10/100/1000M LAN ports（Auto MDI/MDIX） |
| 1 blue system LED indicator, 4 network port LED indicators |
| 1 device pairing/factory reset button |
| 1 power input interface |
| Physical specifications | Dimensions：220x140x36mm (W×D×H, excluding antennas) |
| Weight：0.98kg（entire equipment including packaging） |
| Power supply | Power specification: DC12V 1.5A |
| Maximum power: <14W |
| Certification | CCC，SRRC |
| Operating environment | Operating temperature: 0-45℃ |
| Storage temperature: -40-70℃ |
| Operating humidity: 5%-95%RH (non-condensing) |
| Storage humidity: 5%-95%RH (non-condensing) |
| Main features | Routing mode: PPPoE / DHCP / static IP; relay mode: wired relay / wireless relay |
| Obtain PPPoE account from the old router |
| Wi-Fi dual-band separation/ integration |
| Guest Wi-Fi; smart home Wi-Fi; wireless network isolation |
| Static DHCP address |
| Virtual server: port mapping, DMZ, etc. |
| DDNS: Oray |
| UPnP |
| Network security | Wireless security: WPA-PSK/WPA2-PSK encryption |
| ARP protection: IP/MAC binding |
| SSID hiding |
| Preventing rogue devices (Blacklist/whitelist) |
| Internet access control |
| Advanced features | Reyee Mesh: Supports zero-configuration networking of multiple devices, and supports automatic switching between wired and wireless networking for multiple devices |
| Wi-Fi optimization: Wi-Fi roaming, 5G priority, acceleration mode, channel adjustment, power adjustment, roaming sensitivity adjustment |
| Bandwidth management: hardware NAT, intelligent bandwidth allocation |
| Auto network inspection, fault diagnosis |
| Software upgrade: Automatic & manual cloud software upgrade |
| Management mode | Local web page |
| Cloud management: MACC cloud platform |
| Ruijie Cloud app: iOS version, Android version |
