Wi-Fi Standards | Wi-Fi 5 (IEEE 802.11ac, Wave2) |
Operating Band | 802.11a/n/ac: 5.150~5 .350GHz, 5.470~5.725GHz , 5.725~5 .850GHz (country specific) |
MIMO | 2x2, MU-MIMO |
Max. Wireless Speed | 5 GHz: 867Mbps |
Antenna Gain | Directional, 15 dBi |
Polarization | Horizontal: 31°, Vertical: 14° |
Recommended Distance | 5 KM |
Fixed Ports | 2 x 10/100/1000Base-T |
Memory/Flash | 512 MB/8 MB |
Weatherproof | IP54 |
Transmit Power | ≤400 mW(26 dBm) (adjustable) |
Automatic Pairing | YES |
Point-to-Multipoint | 1:03 |
Management | EWeb/Cloud/APP |
Automatic Restart | YES |
Lightning Protection | 4 kV |
Power Supply | 12 VDC / 24V Passive PoE |
Power Consumption | < 10 W |
Dimensions | 230 mm × 132 mm × 48 mm |
Weight | 0.5 kg |
Operating Temperature | -30°C to 65°C (-22°F ~ 149°F) |
MTBF | > 400,000H |
Certifications | CE, RoHS |
