| Performance |
| Sequential Read Speed* | Up to 3,400 MB/s |
| Sequential Write Speed* | Up to 1,700 MB/s |
| Random Read Speed* | Up to 300,000 IOPS |
| Random Write Speed* | Up to 300,000 IOPS |
| Specification |
| Capacity | 256 GB |
| Cache | 512 MB LPDDR3L |
| Controller | Marvell 88SS1092 |
| NAND Flash | KIOXIA BiCS4 3D TLC |
| Environment and Reliability |
| Power Requirement | DC 3.3V 2.5A (Max.) |
| Temperature | 0℃ ~70℃ / 32℉ ~ 158℉ (Operating) |
| MTBF | >2,500,000 Hours |
| Endurance (TBW) | 160 |
| Warranty | 5 years |
| Compatibility |
| Operating System Supported | Microsoft Windows 8.1, 10/ Linux OS |
| Agency Approval | UL, TUV, FCC, CE, BSMI, VCCI, RCM, KCC, EAC, ROHS, WHQL |
| Command Set Support | TRIM, S.M.A.R.T, IO queue, NVMe™ command |
| Interface | M.2 PCIe® Gen 3 x 4 with NVM Express |
| Firmware Upgrade | Supported |
| Form Factor and Connectors |
| Form Factor | M.2 2280 |
| Power Connector | M.2 connector for DC 3.3V input |
| Data Connector | M.2 Connector |
| Dimension and Weight |
| Dimension (L x W x H) | 80.00 x 22.00 x 2.30 mm / 3.15 x 0.87 x 0.09 inch |
| Weight | 10g / 0.35oz |
