| WAN Port(s) | 1×10/100/1000 Base-T |
| LAN Port(s) | 7×10/100/1000 Base-T 1×1GBase-X SFP |
| LAN/WAN Switchable Port | 2×10/100/1000 Base-T 1×1GBase-X SFP |
| CPU | Dual Core, 880MHz |
| RAM | 256MB |
| Flash | 32MB |
| Concurrent User | 200 |
| Max Throughput | 600Mbps |
| Max VLAN | 8 |
| AP Management | Support, 150 APs |
| WAN Load Balancing | YES |
| PoE/PoE+ | N/A |
| PoE Power Budget,Max. | N/A |
| Captive Portal | YES |
| PPPoE Server | YES |
| Max PPPoE Active Client | 65 |
| Smart Flow Control | YES |
| Application Based Speed Limit | YES |
| Key Application Priority | YES |
| User Group Based Speed Limit | YES |
| Key User Priority | YES |
| Behavior Management | YES |
| PPTP | YES |
| L2TP | YES |
| IPSec | YES |
| OpenVPN | YES |
| Max IPSec Active Tunnels | 8 |
| Max PPTP Active Tunnels | 8 |
| Max L2TP Active Tunnels | 8 |
| Max L2TP Over IPSec Active Tunnels | 8 |
| Max OpenVPN Active Tunnels | 16 |
| Basic Firewall | YES |
| Management | Cloud APP, Cloud Web, Eweb |
| Power Consumption | <18 W |
| Power Supply | 100~240V AC, 50/60Hz |
| Weight | 0.5 kg |
| Dimensions and Rack Units | 202 mm x 108 mm x 28 mm |
| Certifications | CE, ROHS |
