WAN Port(s) | 1×10/100/1000 Base-T |
LAN Port(s) | 9×10/100/1000 Base-T |
LAN/WAN Switchable Port | 3×10/100/1000 Base-T |
CPU | Dual Core, 1.3GHz |
RAM | 256MB |
Flash | 16MB |
Concurrent User | 200 |
Max Throughput | 1Gbps |
Max VLAN | 8 |
AP Management | Support, 150 APs |
WAN Load Balancing | YES |
PoE/PoE+ | N/A |
PoE Power Budget,Max. | N/A |
Captive Portal | YES |
PPPoE Server | YES |
Max PPPoE Active Client | 65 |
Smart Flow Control | YES |
Application Based Speed Limit | YES |
Key Application Priority | YES |
User Group Based Speed Limit | YES |
Key User Priority | YES |
Behavior Management | YES |
PPTP | YES |
L2TP | YES |
IPSec | YES |
OpenVPN | YES |
Max IPSec Active Tunnels | 32 |
Max PPTP Active Tunnels | 32 |
Max L2TP Active Tunnels | 32 |
Max L2TP Over IPSec Active Tunnels | 32 |
Max OpenVPN Active Tunnels | 32 |
Basic Firewall | YES |
Management | Cloud APP, Cloud Web, Eweb |
Power Consumption | <15W |
Power Supply | 100~240V AC, 50/60Hz |
Weight | 2.4kg |
Dimensions and Rack Units | 440 mm × 200 mm × 43.6 mm |
Certifications | CE, ROHS |
