Network Interface | 5 x 10/100/1000 Base-T |
Max. WAN Ports | 4 x 10/100/1000 Base-T |
RAM | 512 MB |
Storage | 256 MB |
Recommended Bandwidth | 1.5Gbps |
Recommended Concurrent Users | 300 |
PoE Out | 802.3af/at on LAN0-3 |
Installation | Desktop |
Power Supply | 100~240V AC, 50/60Hz |
Max. VLAN Qty. | 8 |
Application Based Speed Limit | YES |
Key Application Priority | YES |
User Group Based Speed Limit | YES |
Key User Priority | YES |
Load Balancing | YES |
Behavior Control | YES |
Basic Firewall | YES |
VPN | PPTP, L2TP, IPsec, OpenVPN |
Max VPN Account Quantity | 300 |
Max IPSec Active Tunnels | 64 |
Max PPTP Active Tunnels | 64 |
Max L2TP Active Tunnels | 64 |
Max L2TP Over IPSec Active Tunnels | 64 |
Max OpenVPN Active Tunnels | 64 |
VPN Throughput of OpenVPN | 100Mbps |
VPN Throughput of IPSec | 230Mbps |
VPN Throughput of PPTP&L2TP | 640Mbps |
Captive Portal Authentication | YES |
Multiple LAN Network via VLAN | YES |
PPPoE Authentication Server | YES |
Max PPPoE Client Account | 300 |
Max PPPoE Active Client | 128 |
App Identification | YES |
Intelligent Traffic Control | YES |
Ruijie Free DDNS | YES |
