| Model | RG-NBS3100-24GT4SFP-P |
| Fixed ports | 24 10/100/1000Base-T ports (support PoE and PoE+), 4 SFP 1000Base-X ports, 370W PoE power |
| Switching capacity | 336Gbps |
| Packet forwarding rate | 42Mpps |
| MAC address | Support static MAC address, MAC address filtering |
| MAC address table size | 8K |
| Number of VLANs | 4094 |
| Link aggregation | Support |
| Port mirroring | Many-to-one mirroring |
| Spanning tree | STP, RSTP |
| LLDP | Support |
| ACL | IP standard ACL |
| MAC extended ACL |
| IP extended ACL |
| Port ACL for Layer 2 ports (physical port / AP) |
| QoS | Port-based speed limit (ingress/egress) |
| Security | Port protection |
| Hardware CPP |
| Management | Web management, Ruijie Cloud or Ruijie Cloud app management |
| DHCP | DHCP snooping |
| EEE | Support |
| Physical specifications | |
| Dimensions | 440×293×44mm |
| PoE | 24 Base-T ports (support PoE and PoE+) |
| Maximum PoE / PoE+ output power per switch: 370W |
| Maximum output power per port: 30W |
| Temperature | Operating temperature: 0 ℃ ~ 50 ℃ |
| Storage temperature: -40 ℃ ~ 70 ℃ |
| Humidity | Operating humidity: 10% ~ 90% RH |
| Storage humidity: 5% ~ 90% RH |
