| GPU | AMD Radeon™ RX 6500 XT Graphics Card |
| 6nm GPU |
| AMD RDNA™ 2 Architecture |
| Engine Clock | Boost Clock: Up to 2825 MHz |
| Game Clock: Up to 2685 MHz |
| Boost Clock is the maximum frequency achievable on the GPU running bursty workload. Boost clock achievability, frequency, and sustainabilty will vary based on several factors, including but not limited to: thermal conditions and variation in application and workloads. |
| Game Clock is the expected GPU clock when running typical gaming applications, set to typical TGP(Total Graphics Power). Actual individual game clock results may vary. |
| Stream Processors | 1024 |
| Infinity Cache | 16MB |
| Ray Accelerators | 16 |
| Memory Size/Bus | 4GB GDDR6 |
| Memory Clock | 18 Gbps Effective |
| Displays | Maximum 2 Displays |
| Resolution | HDMI™: 7680×4320 |
| DisplayPort1.4: 7680×4320 |
| Interface | PCI-Express 4.0 |
| Output | 1x HDMI |
| 1x DisplayPort |
| BIOS Support | UEFI |
| Game Index | 1080P |
| Sapphire Features | Premium Digital Power Design |
| Fuse Protection |
| Dual-X Cooling Technology |
| Intelligent Fan Control |
| Precision Fan Control |
| Metal Backplate |
| TriXX Supported |
| TriXX Boost |
| AMD Features | AMD RDNA 2 Gaming Architecture |
| DirectX 12 Ultimate support |
| AMD Smart Access Memory |
| AMD Infinity Cache |
| 6nm GPU |
| PCI Express 4.0 support |
| AMD FreeSync Technology |
| DisplayPort 1.4 with DSC |
| HDMI support |
| Video Streaming up to 8K |
| AMD Radeon VR Ready Premium |
| AMD FidelityFX |
| AMD Radeon Image Sharpening |
| AMD Radeon Anti-Lag |
| AMD Radeon Software |
| Game Driver Optimizations |
| Cooling | Dual Fans |
| Form Factor | 2 slot, ATX |
| Dimension: 194(L)X 107(W)X 40(H)mm |
| Power Consumption | 130W (Board Power) |
| OS | Linux®, Windows® 7*, Windows® 10, and Windows 11 64-bit operating system required |
| *Does not support all features including but not limited to Hardware Raytracing |
| System Requirement | Minimum 400 Watt Power Supply |
| 1 x 6-pin Power Connector. |
| PCI Express® based PC is required with one X16 lane graphics slot available on the motherboard. |
| Minimum 8GB of system memory. 16GB recommended. |
