| GPU | AMD Radeon™ RX 6700 XT Graphics Card |
| 7nm GPU |
| AMD RDNA™ 2 Architecture |
| Engine Clock | Boost Clock: Up to 2581 MHz |
| Game Clock: Up to 2424 MHz |
| Game Clock is the expected GPU clock when running typical gaming applications, set to typical TGP(Total Graphics Power). Actual individual game clock results may vary. |
| Stream Processors | 2560 |
| Infinity Cache | 96MB |
| Ray Accelerators | 40 |
| Memory Size/Bus | 12GB GDDR6 |
| Memory Clock | 16 Gbps Effective |
| Displays | Maximum 4 Displays |
| Resolution | HDMI™: 7680×4320 |
| DisplayPort1.4: 7680×4320 |
| Interface | PCI-Express 4.0 |
| Output | 1x HDMI |
| 3x DisplayPort |
| BIOS Support | UEFI |
| Game Index | 4K |
| Sapphire Features | Premium Digital Power Design |
| Fuse Protection |
| Dual-X Cooling Technology |
| Intelligent Fan Control |
| Precision Fan Control |
| Metal Backplate |
| Two-Ball Bearing Fans |
| Integrated Cooling Module |
| TriXX Supported |
| TriXX Boost |
| AMD Features | AMD RDNA™ 2 Gaming Architecture |
| DirectX® 12 Ultimate |
| Hardware Raytracing |
| Smart Access Memory |
| Infinity Cache |
| 7nm GPU |
| PCI® Express 4.0 Support |
| AMD FreeSync™ Technology |
| DisplayPort™ 1.4 with DSC |
| HDMI™ 2.1 VRR |
| Video Streaming up to 8K |
| Radeon™ VR Ready Premium |
| AMD FidelityFX |
| Radeon™ Image Sharpening |
| Radeon™ Anti-Lag |
| Radeon™ Software |
| Game Driver Optimizations |
| Cooling | Dual Fans |
| Form Factor | 2.2 slot, ATX |
| Dimension: 260(L)X 119.85(W)X 49(H)mm |
| Power Consumption | 230W (Board Power) |
| OS | Linux®, Windows® 7*, Windows® 10, and Windows 8.1. 64-bit operating system required |
| *Does not support all features including but not limited to Hardware Raytracing |
| System Requirement | Minimum 650 Watt Power Supply |
| 1 x 8-pin + 1 x 6-pin Power Connector. |
| PCI Express® based PC is required with one X16 lane graphics slot available on the motherboard. |
| Minimum 8GB of system memory. 16GB recommended. |
